Box Turning Tools
Brazed Box Turning tools allow up to 5/8" Depth per pass
● Available in MicroGrain ideal for most applications
● Specials of all types are also available made to your
specifications.
Brazed Box Turning tools allow up to 5/8" Depth per pass
● Available in MicroGrain ideal for most applications
● Specials of all types are also available made to your
specifications.
Box Turning Tools.
For use in most Box Turning Tool holders.
Provide up to 5/8
depth per pass
For use in most Box Turning Tool holders.
Provide up to 5/8
depth per pass
Copyright 2017 Clapp & Haney Brazed Tool Company, Inc. All rights reserved. Site provided by See Through Solids.
| RH | LH | SHANK DIMENSIONS | TIP | ||||
| STYLE | STYLE | A | B | C | T | W | L |
| BT-4 | BTL-4 | 1/4 | 1/4 | 1-1/2 | 1/8 | 3/16 | 1/4 |
| BT-5 | BTL-5 | 5/16 | 5/16 | 1-134 | 1/8 | 3/16 | 5/16 |
| BT-6 | BTL-6 | 3/8 | 3/8 | 2 | 3/16 | 5/16 | 3/8 |
| BT-7 | BTL-7 | 7/16 | 7/16 | 2-1/4 | 3/16 | 3/8 | 7/16 |
| BT-8 | BTL-8 | 1/2 | 1/2 | 2-1/2 | 3/16 | 3/8 | 1/2 |
| BT-9 | BTL-9 | 9/16 | 9/16 | 2-3/4 | 3/16 | 1/2 | 9/16 |
| BT-10 | BTL-10 | 5/8 | 5/8 | 3 | 1/4 | 1/2 | 5/8 |
