1  Radii CNC ground to +/-.001 tolerance
2  MicroGrain tools have polished top
Concave Radius Tools Shank Overall
Right Hand Right Hand Right Hand Left Hand Height Length Radius
C2 C6 Micro Grain Micro Grain B C R
RT4001 RT4021     1/4 2 .031
RT4002 RT4022     1/4 2 .062
RT4003 RT4023     1/4 2 .093
RT4004 RT4024     1/4 2 .125
    RAD1 RAL1 3/8 2-1/2 .031
    RAD2 RAL2 3/8 2-1/2 .062
    RAD3 RAL3 3/8 2-1/2 .093
    RAD4 RAL4 3/8 2-1/2 .125
RT4101 RT4121 RAD5 RAL5 3/8 2-1/2 .156
RT4102 RT4122 RAD6 RAL6 3/8 2-1/2 .187
    RAD7 RAL7 3/8 2-1/2 .219
RT4103 RT4123 RAD8 RAL8 3/8 2-1/2 .250
    RAD9 RAL9 1/2 3-1/2 .281
RT4021 RT4205 RAD10 RAL10 1/2 3-1/2 .312
    RAD11 RAL11 1/2 3-1/2 .344
RT4202 RT4206 RAD12 RAL12 1/2 3-1/2 .375
    RAD13 RAL13 3/4 4-1/2 .406
    RAD14 RAL14 3/4 4-1/2 .437
    RAD15 RAL15 3/4 4-1/2 .469
RT4301 RT4321 RAD16 RAL16 3/4 4-1/2 .500
Convex Radius Tools Shank Overall
Right Hand Right Hand Right Hand Left Hand Height Length Radius
C2 C6 Micro Grain Micro Grain B C R
RT4005 RT4025     1/4 2 .031
RT4006 4T4026     1/4 2 .062
RT4007 RT4027     1/4 2 .093
RT4008 RT4028     1/4 2 .125
    RXD1 RXL1 3/8 2-1/2 .031
    RXD2 RXL2 3/8 2-1/2 .062
    RXD3 RXL3 3/8 2-1/2 .093
    RXD4 RXL4 3/8 2-1/2 .125
RT4104 RT4124 RXD5 RXL5 3/8 2-1/2 .156
RT4105 RT4125 RXD6 RXL6 3/8 2-1/2 .187
    RXD7 RXL7 3/8 2-1/2 .219
RT4106 RT4126 RXD8 RXL8 3/8 2-1/2 .250
    RXD9 RXL9 1/2 3-1/2 .281
RT4203 RT4207 RXD10 RXL10 1/2 3-1/2 .312
    RXD11 RXL11 1/2 3-1/2 .344
RT4204 RT4208 RXD12 RXL12 1/2 3-1/2 .375
    RXD13 RXL13 3/4 4-1/2 .406
    RXD14 RXL14 3/4 4-1/2 .437
    RXD15 RXL15 3/4 4-1/2 .469
RT4302 RT4322 RXD16 RXL16 3/4 4-1/2 .500
1  Radii CNC ground to +/-.001 tolerance
2  MicroGrain tools have polished top
Concave Radius Tools
LH & RH Styles
Used for forming radii on work piece, rounding sholders on grooves or radius on end of part.
Convex Radius Tools
LH & RH Styles
Used for forming radii on work piece, cutting radius forms on sholders on grooves or radius forms on end of part.
Radius Tools

     We offer:
           * Close Tolerence
           * Concave or Convex in right or left hand
           * We stock all standard sizes
           * Special Radius sizes available to order
