Screw Machine Cutting Tools
Standard brazed cutting tools tailored specifically for the Screw
Machine market for Turning, Forming and Cutoff. Available in
Right and Left hand.
● Available in grades C2. C5. C6 or MicroGrain with
polished tops*
● Specials of all types are also available made to your
specifications.
Standard brazed cutting tools tailored specifically for the Screw
Machine market for Turning, Forming and Cutoff. Available in
Right and Left hand.
● Available in grades C2. C5. C6 or MicroGrain with
polished tops*
● Specials of all types are also available made to your
specifications.
Style RT, LT & C
Turning and Forming Tools.
Used for general purpose turning and forming operations.
Turning and Forming Tools.
Used for general purpose turning and forming operations.
| Standard Brazed Tools -Turning (RT/LT) & Forming (C) | |||||
| Style | Style | Style | Shank Dimensons | ||
| RT | LT | C | A | B | C |
| RT-250 | LT-250 | C-250 | 1/4 | 1/4 | 6" |
| RT-281 | LT-281 | C-281 | 9/32 | 9/32 | |
| RT-312 | LT-312 | C-312 | 5/16 | 5/16 | |
| RT-375 | LT-375 | C-375 | 3/8 | 3/8 | |
| RT-437 | LT-437 | C-437 | 7/16 | 7/16 | |
| RT-500 | LT-500 | C-500 | 1/2 | 1/2 | |
| RT-625 | LT-625 | C-625 | 5/8 | 5/8 | 4" |
| RT-750 | LT-750 | C-750 | 3/4 | 3/4 | |
Style RC & LC
Cut-off Tools.
Used Used for Cutoff operations.
Depth of Cut is 3X the Width of cut
Cut-off Tools.
Used Used for Cutoff operations.
Depth of Cut is 3X the Width of cut
| Standard Brazed Tools - Cutoff | |||||
| Style | Style | Dimensions | |||
| RC | LC | Width | A | B | C |
| RC-250040 | LC-250040 | .040 | 1/4 | 1/4 | 6" |
| RC-281040 | LC-281040 | 9/32 | 9/32 | ||
| RC-312040 | LC-312040 | 5/16 | 5/16 | ||
| RC-375040 | LC-375040 | 3/8 | 3/8 | ||
| RC-250060 | LC-250060 | .060 | 1/4 | 1/4 | 6" |
| RC-281060 | LC-281060 | 9/32 | 9/32 | ||
| RC-312060 | LC-312060 | 5/16 | 5/16 | ||
| RC-375060 | LC-375060 | 3/8 | 3/8 | ||
| RC-437060 | LC-437060 | 7/16 | 7/16 | ||
| RC-500060 | LC-500060 | 1/2 | 1/2 | ||
| RC-625060 | LR-625060 | 5/8 | 5/8 | 4" | |
| RC-750060 | LR-750060 | 3/4 | 3/4 | ||
| RC-281080 | LC-281080 | .080 | 9/32 | 9/32 | 6" |
| RC-312080 | LC-312080 | 5/16 | 5/16 | ||
| RC-375080 | LC-375080 | 3/8 | 3/8 | ||
| RC-437080 | LC-437080 | 7/16 | 7/16 | ||
| RC-500080 | LC-500080 | 1/2 | 1/2 | ||
| RC-6235080 | LC-625080 | 5/8 | 5/8 | 4" | |
| RC-750080 | LC-750080 | 3/4 | 3/4 | ||
| RC-281100 | LC-281100 | .100 | 9/32 | 9/32 | 6" |
| RC-312100 | LC-312100 | 5/16 | 5/16 | ||
| RC-375100 | LC-375100 | 3/8 | 3/8 | ||
| RC-427100 | LC-427100 | 7/16 | 7/16 | ||
| RC-500100 | LC-500100 | 1/2 | 1/2 | ||
| RC-625100 | LC-625100 | 5/8 | 5/8 | 4" | |
| RC750100 | LC-750100 | 3/4 | 3/4 | ||
| RC-375120 | LC-375120 | .120 | 3/8 | 3/8 | 6" |
| RC-436120 | LC-436120 | 7/16 | 7/16 | ||
| RC-500120 | LC-500120 | 1/2 | 1/2 | ||
| RC-625125 | LC-625125 | .125 | 5/8 | 5/8 | 4" |
| RC-750125 | LC-750125 | 3/4 | 3/4 | ||
| RC-625187 | LC-625187 | .187 | 5/8 | 5/8 | 4" |
| RC-750187 | LC-750187 | 3/4 | 3/4 | ||
* Polished Tops on MicroGrain only
